• APPLICATION

    Color Matched Screws for Pressure Treated Lumber and PVC Trim.

    • Flat Head—For use in pressure treated decking.
    • Trim Head—For use in pressure treated trim and finish applications.

  • FEATURES

    • For excellent corrosion resistance and color matching with various types of treated lumber and PVC trim (Gray, Green, Red, Tan, White)
    • Lengths from 1-1/4″ to 6″
    • Reinforced flat or trim head with nibs for better countersinking
    • Extra deep star drive recesses to prevent cam-out
    • Type 17 auger tip for faster, easier insertion and to help prevent splitting

  • INSTALLATION

    • Install flush with decking surface. Do not overdrive.
    • Install two screws per joist.
    • Predrilling is recommended when fastening within 1-1/2″ from the end of a deck board.

AVAILABLE COLORS

  • GRAY
    #57

  • GREEN
    #91

  • RED
    #84

  • TAN
    #62

  • WHITE
    #39

*White (#39) available only in Trim Head—2" and 2-1/2" lengths

  • FLAT Head Packaging

    LENGTH DRIVE TYPE COUNT PACKAGING POUND PACKAGING
    RETAIL PACKS JOB PACKS BULK 1 LB 5 LBS 9 LBS
    1-1/4″ T-20 100 500 8000 • • •
    1-5/8″ 100 500 5000 • • •
    2″ 100 500 3500 • • •
    2-1/2″ T-25 75 250 2500 • • •
    3″ 75 250 2000 • • •
    3-1/2″ 50 250 1000 • • •
    4″ 50 250 1000 • • •
    5″ 30 – 500 • • •
    6″ 30 – 500 • • •

  • Trim Head Packaging

    LENGTH COUNT PACKAGING POUND PACKAGING
    DRIVE TYPE RETAIL PACKS JOB PACKS BULK 1 LB 5 LBS 9 LBS
    1-5/8″ T-20 100 500 5000 • • •
    2″ 100 500 3500 • • •
    2-1/2″ 75 250 2500 • • •
    3″ 75 250 2000 • • •
    3-1/2″ 50 250 1000 • • •
    4″ 50 250 1000 • • •

FINISH

Epoxy Coated

CORROSION

Exterior Use

Approved for use in ACQ and pressure treated lumber.

For salt water or other areas where corrosion is a concern, use Grade 316 Stainless.

DRIVE SYSTEM

Star drive

TOOL COMPATIBILITY

SMART-BIT® Depth Setter Tool
